AFRL’s new equipment, a Split-Hopkinson Pressure Bar system, measures stress at high strain rates and helps analyze material behavior under severe conditions. Engineers from AFRL’s Rocket Propulsion Division at Edwards Air Force Base, California will use the system to test and gather data from solid propellants and space-bound materials. (U.S. Air Force photo/Joy Alich)

PHOTO BY: Joy Alich
